Framefit what is it ? & Installation Guide

Framefit is a highly effective solution for sealing and protecting fire-rated frames and openings. Its versatility and ease of installation make it an essential component for achieving passive fire protection in buildings. In this guide, we’ll walk you through the installation process and provide tips to ensure optimal performance.

In the UK, an estimated 30 million fire doors are non-compliant, with 80% failing due to excessive gaps between the door and frame. Common problem areas include the lock side, head, and bottom of doors.

Fire door regulations specify that gaps must not exceed 4mm between the frame and leaf, 8mm at the bottom of fire-only doors, and 3mm at the bottom of fire and smoke doors.

FrameFit is a fully tested, cost-effective solution that eliminates excessive gaps, enabling existing fire doors to meet compliance standards. It attaches to frames and door bottoms, saving thousands of doors from unnecessary replacement, reducing costs, and minimizing waste.

what versions of FrameFit is there?

HE1.5/44 (FD30) or HE1.5/54 (FD60) – High Expansion Intumescent

This profile is designed for use as the top layer when both fire and cold smoke seals are required. The strip in the frame needs removing and also if there is no strip at all. It is particularly suitable for scenarios where the existing fire and smoke seal is routed into the door frame.

LM/44 or LM/54 – Low Modulus Fire-Retardant Spacer Profile

Available in three thicknesses (1.5mm, 3mm, and 5mm), and in widths of 44mm (FD30) or 54mm (FD60). These profiles are designed to be used in various combinations to reduce excessive gaps.

• If the fire and smoke seals are located in the door edge, the LM profiles can be used independently without requiring the HE1.5 profile.

Key Benefits of Framefit:

• Ensures compliance with fire door regulations.
• Affordable alternative to door replacement.
• Environmentally friendly by reducing waste.
• Quick and easy to install.

FrameFit revolutionizes fire door remediation, addressing a critical safety issue while promoting sustainability and cost savings.

Why Choose Framefit?

Framefit is designed to enhance fire resistance by sealing gaps around fire-rated frames. Key benefits include:

• Easy Application: Straightforward installation process.
• Versatility: Suitable for various frame types and materials.
• Durability: Maintains effectiveness over time, even under challenging conditions.
• Compliance: Meets industry fire safety standards.

Tools and Materials Needed

Before starting, gather the following tools and materials:

• Framefit product (intumescent or non-intumescent sealant)
• Utility knife or scissors
• Measuring tape
• Cleaning cloth or brush
• Gloves and safety glasses

Pre-Installation Checklist

1. Inspect the Area: Ensure the frame and surrounding surfaces are clean, dry, and free of debris or dust.
2. Measure the Gap: Use a measuring tape to confirm the gap size around the frame is within the product’s specified tolerances.
3. Check for Compatibility: Verify that the frame material is suitable for Framefit.

Step-by-Step Installation Guide

Prepare the Surface

• Remove any dirt, grease, or loose particles from the installation area using a cleaning cloth or brush.
• Ensure the surface is completely dry before proceeding.

Select the Appropriate Profile

• Choose the correct FrameFit profile based on the fire rating of the door:

• FD30: 44mm wide
• FD60: 54mm wide

Measure the Gap

• Measure the existing gap between the door edge and the frame. Use this measurement to determine the FrameFit components needed to reduce the gap to 2mm to 4mm (refer to the Gap Guide and Profiles).

Cut and Fit Components

• Cut and install the selected FrameFit components onto the door frame only. Ensure the intumescent HE strip is installed last, positioned to face the door edge without any obstructions.

Initial Fixing with Adhesive

• Use the double-sided adhesive tape on the back of each profile to temporarily secure the LM profiles to the frame.

Permanent Fixing

• once all spacers are in place, fix them permanently by screwing or pinning through all layers into the door frame at 400mm intervals.

Smoke Seal Installation (if needed)

• For doors requiring a smoke seal, install the HE1.5 profile as the final top layer.

Smooth and Adjust

• Use a gloved finger or a smoothing tool to ensure the sealant is evenly distributed.
• For pre-formed strips, double-check that they are securely in place and fill any remaining gaps if necessary.

Clean Up

• Remove any excess material with a damp cloth before it hardens.
• Clean tools and dispose of waste according to local regulations.

Post-Installation Tips

1. Inspect the Installation: Check for any missed gaps or uneven application.
2. Regular Maintenance: Periodically inspect the installation to ensure it remains intact and effective.

Compliance and Certification

Framefit products are rigorously tested and comply with fire safety standards. Always consult the product’s datasheet for specific compliance details to meet building code requirements.

Conclusion

Installing Framefit is a straightforward yet critical step in enhancing passive fire protection for your building. By following this guide, you’ll ensure a reliable and durable fire-rated seal that stands the test of time. For further assistance or to learn more about Framefit, feel free to contact our expert team.

Protect. Seal. Secure.

Any further questions don’t hesitate to contact the technical team at [email protected] or on 01752690997
