Hempafire Extreme 550 is a two component epoxy solvent-free, chemically curing intumescent coating for passive fire protection of structural steel against cellulosic fires.
It is optimized from R30 to R120 fire durations and for in-shop applications. Fire protection at R180 and R240 may be possible depending on the project.
On-site applications may be possible depending on the equipment and set up.
As intumescent fire protection for structural steel in interior and exterior service conditions, up to Type X (EAD350402-00-1106 / EN 16623) and C5 conditions (ISO 12944-2). Suitable for I section beams, H columns, hollow sections and cellular beams. As a repair and touch-up coating for damaged areas of Hempafire Extreme 550.
Features
– Very competitive thicknesses resulting in reduced paint consumption and less coats to apply.
– Wide coverage of protectable Hp/A, allowing the use of light steel sections for higher fire ratings.
– Fire protection up to 4 hours. Optimized for the range of R30 toR120.
– Excellent durability towards mechanical damages, chemical resistance and weather exposure.
– Weather resistant and up to C5 conditions without topcoat. Topcoat only needed for aesthetic purposes.
– Smooth surface and compatible with a wide range of topcoats, allowing the desired Aesthetic finish of the steel.
– Reduced application costs and Fast process time, combining high DFT/coat with a reduced total PFP thicknesses to apply. Protection achieved in less coats.
– One product for most common steel sections to reduce complexity in application and specification.
– It has been approved and 3rd party certified according to EN13381- 8 and BS 476-21. It has ETA with CE mark and ApplusFire approvals.
– Can be applied up to 3-5 mm [118-196 mils] dry film thickness per coat (depending on the set up), thus providing the required protection in less coats.
– Optimized to maximize throughput and DFT/coat with plural feed application equipment. Application with single leg equipment also possible for touch ups / small areas.
– Solvent free / 100% solids, product has very low VOC. Environmental Product Declaration with third-party certification is ongoing (Type III EPD, acc. to ISO 14025, EN 15804). Product can contribute to EPD credits for LEED and BREEAM projects.
– Complies with EU Directive 2004/42/EC, The Paints Directive on the limitation of volatile organic compounds: subcategory i.
Certificates / Approvals
– Assessed according to EN 13381-8, fire resistance of structural steel up to R240
– Tested and assessed according to BS 476-21: Standard for Fire Test on Building Materials and structures; determination of the fire resistance of loadbearing elements of construction. Up to R240
Product safety
Flash point 184°C [363°F]
VOC content mixed product
Legislation EU | Value 9 g/L [0.08 lb/US gal]
According to ISO 11890-1.
Handling
Handle with care. Before and during use, observe safety labels on packaging and paint containers and follow all local and national safety regulations. Always consult Hempel’s Safety Data Sheet for this product along with the Product Data Sheet.
For professional use only.
